Display
| Projection System‎ | DLP Single 0.65″ 1080P |
|---|
| DMD Type | DC3 DMD Chip |
|---|
| Resolution‎ | 1920×1080 pixels |
|---|
| Brightness | 3,500 ANSI Lumens |
|---|
| Contrast Ratio‎ | 10000:1 |
|---|
| Display Color‎ | 1.07 Billion Colors |
|---|
| Aspect Ratio | Native 16:9 (6 aspect ratio selectable) |
|---|
| Light Source | Lamp (280W) |
|---|
| Light Source Life‎* | 3000/4000/7000 hours (Normal/Eco/SmartEco mode) |
|---|
Optical
| Throw Ratio | 0.33 |
|---|
| Zoom Ratio | Fixed |
|---|
| Lens | F=2.5, f=5.1mm‎ |
|---|
| Keystone Correction | 2D; Vertical ± 15 degrees, Horizontal ± 15 degrees |
|---|
| Lens Control | Manual Zoom and Focus |
|---|
| Projection Offset** | 125% |
|---|
| Projection Size (diagonal) | 88.8″ ~ 110″‎ |
|---|
Audio
| Built-in Speaker | 20W (10Wx2) |
|---|
Security
| Security Lock | Kensington Lock Security Bar |
|---|
Connectivity
| I/O Port | HDMI x 2 (HDMI-1 share with MHL) PC In (D-sub 15pin) x 2 (share with component video) Monitor Out (D-sub 15pin) x 1 Composite Video In (RCA) x 1 S-Video In x 1 Audio In (mini jack) x 1 Audio L/R In (RCA) x 1 Audio Out (mini jack) x 1 LAN RJ45 x 1 (LAN control) RS232 (DB-9pin) x 1 USB (type A) x 1 (5V 2A power supply) USB (type B) x1 (firmware download) USB (type mini B) x 1 (optional interactive camera) IR Receiver x1 (front) |
|---|
Compatibility
| Resolution Support | VGA (640 x 480) to WUXGA (1920 x 1200) |
|---|
| Horizontal Frequency | 15K – 102kHz |
|---|
| Vertical Scan Rate | 23 – 120Hz |
|---|
| HDTV Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
|---|
| Video Compatibility | NTSC, PAL, SECAM |
|---|
Power
| Power Consumption (Max/Normal/Eco) | Max 400W. Normal 380W. Eco 320W |
|---|
| Standby Power Consumption | Network<2W, Standby<0.5W |
|---|
| Power Supply | AC100V to 240V, 50Hz to 60Hz‎ |
|---|
Dimension and Weight
| Product Dimensions (WxHxD) | 373.3 x 130.2 x 287.5mm (w/o mirror) 373.3 x 201 x 287.5mm (w/ mirror)‎ |
|---|
| Product Weight | 5kg (w/o wall mount plate)‎ |
|---|
Operation Condition
| Noise Level (Normal/Eco) | 37/33 dBA |
|---|
| Operating Temperature | 0o ~ 40o C |
|---|
Accessories
| Accessories (Standard) | Remote Control w/ Battery RCS011 x 1 Power Cord (by region) x 1 User Manual CD x 1 Quick Start Guide x 1 Warranty Card (by region) x 1 VGA (D-sub 15pin) Cable x 1 Wall Mount Kit (with installation guide) x 1 |
|---|
| Accessories (Optional) | Spare Lamp Kit 5J.JDT05.001 3D Glasses DGD5 5J.J9H25.001 Document Camera S30 9H.J9L78.T3E PointWrite Kit PW01U 5J.J8L26.20E PointWrite Touch Module PT12 5J.J8L26.13E |
|---|
OSD
| On Screen Display Language | Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 languages) ‎ |
|---|
