Panel
- Diagonal Size46″
- Resolution1920*1080 (Full HD)
- Pixel Pitch(mm)0.53mm(H) X 0.53mm(V)
- Active Display Area(mm)1018.08(H) x 572.67(V)
- Brightness(Typ.)3000 nit
- Contrast Ratio5000:1
- Viewing Angle(H/V)178/178
- Display Colors8 bit – 16.7M
- Color Gamut72%
- Haze0%
Display
- Dynamic C/R100,000:1
- H-Scanning Frequency30 ~ 81 kHz
- V-Scanning Frequency48 ~ 75 Hz
- Maximum Pixel Frequency148.5 MHz
Sound
- Speaker TypeN/A
Connectivity
Input
- RGBN/A
- VideoHDMI 1.4 (2), HDBaseT(LAN Common)
- HDCPHDCP 2.2
- AudioN/A
- USBUSB 2.0 x 1
Output
- RGBN/A
- VideoN/A
- AudioStereo Mini Jack
- Power OutN/A
- External ControlRS232C (In/Out), RJ45(In/Out), HDBaseT
- External SensorN/A
- TunerN/A
Power
- TypeInternal
- Power SupplyAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
- Max[W/h]468
- Typical[W/h]W/W(EU) 193 US/KOR/Etc. 440 ※ Etc: CHINA, TAIWAN, BRA, CIS
- BTU(Max)1,596
- Sleep modeLess than 0.5W
- Off modeLess than 0.5W
Mechanical Specification
Dimension (mm)
- Set1069.0 X 623.6 X 85.0
- Package1156 x 713 x 200
Weight (kg)
- Set40.5Kg
- Package44.3Kg
- VESA Mount (mm)N/A
- Mounting Hole995 x 500 (Basic) 1000 x 400 (VESA Bracket Option)
- Protection GlassYes (5T Tempered Glass)
- Stand TypeN/A
- Media Player Option TypeN/A
- Bezel Width (mm)24.9 / 24.9 / 24.9 / 24.9 mm
Operation
- Recommended Usage Hours24/7
- Operating Temperature-30.0 ℃ ~ 50.0 ℃
- Humidity10.0 % ~ 80.0 %
- IP CertificateIP56
Feature
- Key FeaturesPower-box Integrated, IP56 Outdoor, Built-in MagicInfo Player S4, SSSP 4.0
- Special FeaturesIP56 Certified for Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock
Internal Player
- ProcessorCortex-A12 1.3GHz Quad Core CPU
- On-Chip Cache MemoryL1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
- Clock Speed1.3GHz CPU Quad
- Main Memory Interface2.5GB 3 channel 96bit DDR3-933 (1866MHz)
- Graphics2D & 3D Graphics Engine – Up to 3840x2160p. 32bpp – Supports OpenGL ES
- Storage (FDM)8GB (3.75GB Occupied by O/S, 4.25GB Available, )
- MultimediaVideo Decoder – MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC – VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio DSP (Decoder) – AC3 (DD), MPEG, DTS and etc.
- IO PortsUSB 2.0
- Operating SystemTizen 2.4 (VDLinux)
Certification
- SafetyCB : IEC60950-1/EN60950-1 (EN) UL : cUL60950-1 (GO)
- EMCCE : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 (EN) FCC : Part 15, Subpart B Class A (GO)
Accessory
- IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
- StandN/A
- MountN/A
- SpecialtyN/A
Media Player
Media Player
- Media PlayerN/A
