Panel
- Diagonal Size55″
- TypeLED BLU
- Resolution1920*1080 (Full HD)
- Pixel Pitch(mm)0.63mm(H) X 0.63mm(V)
- Active Display Area(mm)1209.60(H) x 680.40(V)
- Brightness(Typ.)2500 nit
- Contrast Ratio4000:1
- Viewing Angle(H/V)178/178
- Response Time(G-to-G)8ms
- Display Colors8 bit – 16.7M
- Color Gamut72%
- Haze0%
Display
- Dynamic C/R100,000:1
- H-Scanning Frequency30 ~ 81 kHz
- V-Scanning Frequency48 ~ 75 Hz
- Maximum Pixel Frequency148.5 MHz
Sound
- Speaker TypeN/A
Connectivity
Input
- RGBN/A
- VideoHDMI 1.4 (2), HDBaseT(LAN Common)
- HDCPHDCP 2.2
- AudioN/A
- USBUSB (1)
Output
- RGBN/A
- VideoN/A
- AudioStereo Mini Jack
- Power OutN/A
- External ControlRS232C (In/Out), RJ45(In/Out), HDBaseT
- External SensorN/A
- TunerN/A
Power
- TypeInternal
- Power SupplyAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
- Max[W/h]450
- Typical[W/h]W/W(EU) 267 US/KOR/Etc. 410 ※ Etc: CHINA, TAIWAN, BRA, CIS
- BTU(Max)1,536
- Sleep modeLess than 0.5W
- Off modeLess than 0.5W
Mechanical Specification
Dimension (mm)
- Set1260.6 X 731.4 X 85.0
- Package1358 x 845 x 230
Weight (kg)
- Set46.1 kg
- Package52.6 kg
- VESA Mount (mm)N/A
- Mounting Hole1186 x 560 (Basic) 1200 x 400 (VESA Bracket Option)
- Protection GlassYes (5T Tempered Glass)
- Stand TypeN/A
- Media Player Option TypeN/A
- Bezel Width (mm)24.9 / 24.9 / 24.9 / 24.9 mm
Operation
- Recommended Usage Hours24/7
- Operating Temperature-30.0 ℃ ~ 50.0 ℃
- Humidity10.0 % ~ 80.0 %
- IP CertificateIP56
Feature
- Key FeaturesPower-box Integrated, IP56 Outdoor, Built-in MagicInfo Player S4, SSSP 4.0
- Special FeaturesIP56 Certified for Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, HD Base T for Long Distance Installalling, Portrait /Landscape Installation Support, Lamp Error Detection, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock
Internal Player
- ProcessorCortex-A12 1.3GHz Quad Core CPU
- On-Chip Cache MemoryL1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB
- Clock Speed1.3GHz CPU Quad
- Main Memory Interface2.5GB 3 channel 96bit DDR3-933 (1866MHz)
- Graphics2D & 3D Graphics Engine – Up to 3840x2160p. 32bpp – Supports OpenGL ES
- Storage (FDM)8GB (3.75GB Occupied by O/S, 4.25GB Available, )
- MultimediaVideo Decoder – MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC – VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio DSP (Decoder) – AC3 (DD), MPEG, DTS and etc.
- IO PortsUSB 2.0
- Operating SystemTizen 2.4 (VDLinux)
Certification
- SafetyCB (Europe) : IEC60950-1/EN60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : PSB+IEC60950-1 NOM (Mexico) : NOM-001-SCFI-1993 IRAM (Argentina) : IRAM+IEC60950-1 SASO (Saudi Arabia) : SASO+IEC60950-1 BIS(India) : IEC60950-1 / IS13252 NOM(Mexico) : NOM-019-SCFI-1998 KC(Korea) : K 60950-1 EAC(Russia) : EAC+IEC60950-1 INMETRO(Brazil) : INMETRO+IEC60950-1 BSMI(Taiwan) : BSMI+IEC60950-1 RCM(Australia) : IEC60950-1/AS/NZS 60950-1 UL(USA) : cUL60950-1 CSA (Canada) : cUL TUV (Germany) : CE NEMKO (Norway) : CE
- EMCFCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003 VCCI (Japan) : VCCI V-3 /2010.04 Class A KCC/EK (Korea) : KN22 / 24 BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital) C-Tick (Australia) : AS/NZS CISPR22:2009 CCC(China) :GB9254-2008 GB17625.1-2012 GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003
Accessory
- IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
- StandN/A
- MountN/A
- SpecialtyN/A
Media Player
Media Player
- Media PlayerN/A
