| Installation |
Landscape |
| LCD Panel |
|
65-inch-class (64 1/2-inch [163.9 cm] diagonal) TFT LCD |
| Max. Resolution |
1,920 x 1,080 pixels |
| Max. Display Colours (approx.) |
16.77 million colours |
| Pixel Pitch (H x V) |
0.744 x 0.744 mm |
| Max. Brightness (average)*1 |
350 cd/m2 |
| Contrast Ratio |
5,000 : 1 |
| Viewing Angle (H/V)*2 |
178°/178° (CR ≥ 10) |
| Active Screen Area (W x H) (approx.) |
1,428.5 x 803.5 mm (56 1/4″ x 31 5/8″) |
| Response Time |
6.5 ms (grey to grey, avg.) |
| Backlight |
LED, edge lit |
| Touchscreen |
Touch Technology |
IR (infrared blocking detection method) |
| PC Connection Port |
USB (2.0 compliant) (Type B) x 1 |
| Power Supply |
Supplied from main unit |
| Multi Touch |
10 points |
| Protection Glass |
Thickness: Approx. 4.1 mm*3Â Â Â Â Shock resistance: 130 cm*4 |
| Touch Pen |
Function Button |
N/A (passive pen) |
| Computer Input |
Video |
Analogue RGB (0.7 Vp-p) [75 Ω], HDMI™, DisplayPort™ |
| Synchronisation |
Horizontal/vertical separation (TTL: positive/negative) |
| Plug & Play |
VESA DDC2B |
| Power Management |
VESA DPMS |
| Input Terminals*5 |
PC analogue: Mini D-sub 15-pin x 1, HDMI x 4 (HDCP and 1080p compatible, PC / AV signal compatible), DisplayPort (HDCP compatible, PC signal compatible) x 1, 3.5 mm-diameter mini stereo jack x 1, RS-232C D-sub 9-pin x 1 |
| Output Terminals*5 |
3.5 mm-diameter mini stereo jack x 1 |
| USB Hub Function |
USB 2.0 (type A) x 2 |
| Expansion Slot |
12 V, 2.4 A (power supplied when expanding the functions with an optional part) |
| Speaker Output |
10 W + 10 W |
| Mounting |
VESA (4 points), 400 x 400 mm, M6 screw |
| Power Supply*6 |
100 V – 240 V AC, 50/60 Hz |
| Power Consumption |
205 W |
| Environmental Conditions |
Operating Temperature |
5°C to 35°C |
| Operating Humidity |
20% to 80% RH (no condensation) |
| Dimensions (W x D x H) (approx.) (display only) |
1,521 x 99 x 952 mm (59 7/8″ x 3 7/8″ x 37 1/2″) |
| Weight (approx.) |
57.5 kg (126.8 lbs) |
| Main Accessories |
AC power cord, remote control unit, battery (AAA size) x 2, set-up manual, blank sticker, cable clamp x 3, USB cable*7, pen tray, pen tray mounting screw x 2, touch pen, camera mount, camera mount screw x 2, camera screw, CD-ROM, SHARP Display Connect license |
