Display System
Display System
4K SXRD panel, projection system
Display device
Size of effective display area
0.74” x 3
Number of pixels
26,542,080 (4096 x 2160 x 3) pixels
Projection lens
Focus
Powered
Zoom
Powered (Approx. x2.06)
Lens shift
Powered
Vertical: +85% -80% Horizontal: +/-31%
Vertical: +85% -80% Horizontal: +/-31%
Light source
Light source
Laser diode
Screen size
Screen size
60” to 300” (1,524 mm to 7,620 mm)
Light output
Light output
2,000 lm
Colour light output
Colour light output
2,000 lm
Dynamic contrast
Dynamic contrast
∞:1
Displayable scanning frequency
Horizontal
19 kHz to 72 kHz
Vertical
48 Hz to 92 Hz
Display resolution*1
Computer signal input
Maximum display resolution: 1920 x 1080 dots (HDMI Input only)
Video signal input
480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, 1080/24p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 3840 x 2160/50p, 3840 x 2160/60p, 4096 x 2160/24p, 4096 x 2160/25p, 4096 x 2160/30p, 4096 x 2160/50p, 4096 x 2160/60p
OSD language
OSD language
18-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic)
INPUT OUTPUT (Computer / Video / Control)
HDMI1 / HDMI2*2
Digital (RGB/Y Pb/Cb Pr/Cr)
Trigger
Minijack, DC 12 V Max. 100 mA
Remote
RS-232C, D-sub 9-pin (male)
LAN
RJ45, 10Base-T/100BASE-TX
IR IN
Mini Jack
USB
DC 5 V, Max. 500 mA
Acoustic noise
Acoustic noise
24 dB*3
Operating temperature / Operating humidity
Operating temperature / Operating humidity
5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity
-20°C to +60°C (-4°F to +140°F) / 10% to 90% (no condensation)
Power requirements
Power requirements
AC 100 V to 240 V, 4.3 A to 1.8 A, 50/60Hz
Power consumption
Power consumption
430 W
Standby
0.4 W (when “Remote Start” is set to “Off”)
Networked Standby
1.0W (LAN) (when “Remote Start” is set to “On”)
When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W).
When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W).
Standby Mode / Networked Standby Mode Activated
Standby Mode / Networked Standby Mode Activated
After about 10 Minutes
3D
3D capability
Yes
3D emitter
Built-in RF emitter
3D glasses
TDG-BT500A (Optional)
Please contact your Sony representative for specific models available in your region.
Please contact your Sony representative for specific models available in your region.
Dimensions (W x H x D) (without protrusions)
Dimensions (W x H x D) (without protrusions)
560 x 223 x 496 mm
22 1/16 x 8 25/32 x 19 17/32 inches
22 1/16 x 8 25/32 x 19 17/32 inches
Mass
Mass
Approx. 20 kg / 44 lb
Supplied accessories
Supplied accessories
RM-PJ24 Remote Commander (1)
Size AA (R6) Manganese Batteries (2)
Lens Cap (1)
AC Power Cord (1)
Operating Instructions (CD-ROM) (1)
Quick Reference Manual (1)
Safety Regulations (1)
Size AA (R6) Manganese Batteries (2)
Lens Cap (1)
AC Power Cord (1)
Operating Instructions (CD-ROM) (1)
Quick Reference Manual (1)
Safety Regulations (1)
Notes
*1
Displayed image may be converted for some input signals.
*2
Both HDMI inputs are compatible with HDCP 2.2.
*3
This value is approximate. Depends on the projector setting condition and usage environment.
