Electrical
Power supply (supplied by PLM‑8M8)
Voltage range 30 – 50 VDC
Power consumption 1.5 W
Performance
Microphone type Cardoid
Frequency response (-3dB) 100 Hz to 20 kHz (+0/‑3 dB)
Input Clip level -11 dBu (-13.3 dBV)
THD+N (1 kHz, 6 dBFS): <0.03 %
• Dynamic range (A‑weighted)
(mid gain setting)
>97 dB(A)
• Output level 24.4 dBu (22.2 dBV)
Connectors 2x
RS485 loop‑through RJ45
Mechanical
Base dimensions (H x W x D) 50 x 156 x 140 mm
(2 x 6.1 x 25.5 in)
Microphone stem length 390 mm (15.35 In)
Color Trafic black (RAL 9017)
Silver (RAL 9006)
Weight Approx. 0.77 kg
Approx. 1.69 lb
Environmental
Operating temperature -10 ÂşC to +45 ÂşC
Storage temperature -40 ÂşC to +70 ÂşC
Relative humidity <95%
Bosch PLM-8CS PLENA matrix 8 Zone Call Station
- Capacitive touch
- Programmable zone selection
- Modern aesthetic design
- Powered from PLM‑8M8
Loop‑through to connect with either more Call
Stations or Wall Control Panels
$138,72
